Aura Car Audio Fireball-6.8 MKII DSP

External wiring controller (purchased separately) AC-1

Product Overview:

Elevate your audio experience with the Aura Fireball-6.8 DSP Amplifier, where cutting-edge technology meets unparalleled performance. Designed to meet the demands of audiophiles and professionals alike, this DSP amplifier redefines excellence in sound engineering.

Accessories

• DSP Amplifier – 1 Pc

• Wiring Harness – 2 Pc

• PC USB Cable – 1 Pc

• Instruction Manual – 1 Pc

  1 YEAR BRAND WARRANTY



  AUDIO
  RMS Power:	25W RMS * 8CH @4-0HMS : 50W RMS* 8CH@ 2-0HMS
  Frequency Response:	20Hz~20kHz
  DSP Processor:	Cirrus Logic
  Signal Converter A/D :	Cirrus Logic
  Signal Converter D/A:	Cirrus Logic
  Bluetooth :	Built in Bluetooth 5.1
  High level speaker input:	6CH
  Low level AUX input:	2CH
  High level speaker output:	8CH
  Low Level RCA Output	8CH
  DSP RCA output:	8CH (RMS 2V)
  High input impedance:	13 Ω
  Low input sensitivity:	0.5-2.5V
  High input sensitivity:	4-10V
  Optical Input:	Yes
  Sampling Rate:	24Bit/192KHz ADC/DAC
  EQ/Delay:	31Band EQ/15ms
  Filtering Crossing Point:	20-20KHz
  PC connections:	USB 2.0
  Software/PC requirements:	Microsoft Window (32/64bit): (XP, Vista, Windows 7, Windows 8, Windows 10)
  Operate temperature range:	-30~70?
  Size:	195(L)x131(W)x46.5(H)mm
  Weight (Kgs)	1.3 Kgs

Advanced Connectivity Options

• Versatile Inputs: With 6 High Level inputs, 2 RCA inputs, Optical input, Bluetooth, and USB connectivity, the Fireball-6.8 ensures compatibility with a wide range of devices, from traditional audio sources to modern digital platforms.

• Precise Input Voltage Management: Experience optimal signal reception with input voltage ranging from 0.5V to 10V for High Level inputs and 0.5V to 5V for RCA inputs.

Exceptional Output Capabilities

• Powerful Output: Delivering unparalleled performance, the Fireball-6.8 offers 8 High Level outputs and 8 RCA outputs, capable of handling up to -10Vrms on the amplifier output and 2Vrms on RCA outputs.

• High-Fidelity Amplification: Utilizing Class AB amplifier technology, this amplifier provides a robust power output of 8x25W @ 4 OHMS and 8x50W @ 2 OHMS, ensuring crystal-clear sound reproduction.

State-of-the-Art Signal Processing

• Intelligent Signal Conversion: Equipped with Cirrus Logic Smart HiFi 3-core DSP, the Fireball-6.8 ensures precise AD & DA signal conversion, maintaining fidelity at every stage of audio processing.

• Enhanced Sampling Rate: Experience audio in its purest form with a sampling rate of 24Bit/192KHz ADC/DAC, delivering unparalleled clarity and detail.

Customizable Audio Control

• Fine-Tuned Equalization: Tailor your audio experience with a 31-band EQ and 15ms delay, offering precise control over frequency response and time alignment.

• Flexible Filtering Options: Choose from Butter, Bessel, and Link filters with adjustable crossover points and slopes, ranging from 6dB/oct to 48dB/oct.

Seamless Integration and Control

• Intuitive User Interface: Seamlessly navigate settings and presets with the Aura Fireball-6.8 PC software, Android, and iOS apps, adorned with our brand logo for easy identification.

PC SOFTWARE/IOS & ANDROID APP- 31-Band EQ/X-Over/Master Volume Control/ Time Delay

Aura PC Software and Mobile App Logo

• Effortless Bluetooth Connectivity: Stream your favourite music wirelessly with Bluetooth 5.1, ensuring stable connections and high-quality audio playback.

Reliability and Convenience

• Robust Construction: Engineered with high-quality components, the Fireball-6.8 boasts a signal-to-noise ratio of 87dB for power amplification and 85dB for RCA inputs, delivering pristine sound quality.

• Efficient Power Management: Operate within a wide voltage range of 9-16V, with a static current of just 0.45A and a working current range of 0.5-18A, ensuring efficiency and reliability.

LCD Remote DSP Controller ( Optional- To Be Purchased Separately): Select source selection, FF/RW Tracks, Change mode are some of function which can be operated through the remote controller.

Illuminate your audio journey with the Aura Fireball-6.8 DSP Amplifier and immerse yourself in a world of unparalleled sound quality and performance. Experience the future of audio technology today.

 Frequently Asked Questions:

1. What is the Aura Fireball 6.8 DSP amplifier used for?

The Aura Fireball 6.8 DSP is an 8-channel DSP amplifier designed to improve your car's sound quality by offering precise audio tuning, amplification, time alignment, crossover settings, and equalization.

2. Is the AC-1 remote included with the amplifier?

No. The AC-1 LCD remote controller is an optional accessory and must be purchased separately. It allows convenient control of volume, source selection, presets, and playback functions.

3. Can I connect this DSP amplifier to my factory stereo?

Yes. The amplifier supports high-level speaker inputs, making it compatible with many factory-installed head units without requiring major modifications.

4. Does the amplifier support Bluetooth audio streaming?

Yes. It features built-in Bluetooth 5.1 for stable wireless music streaming from compatible smartphones and devices.

5. Can I tune the sound using a mobile app or PC?

Yes. The Aura Fireball 6.8 DSP can be configured using Windows PC software as well as Android and iOS applications for advanced audio tuning.

6. Is this amplifier suitable for aftermarket speaker upgrades?

Yes. It works well with aftermarket speakers and can be integrated into custom car audio systems requiring multiple channels and DSP tuning.

7. Does it support subwoofer integration?

Yes. The DSP provides multiple output channels and crossover controls, allowing seamless integration with external amplifiers and subwoofers for a complete audio system.

8. What tuning features are available?

The amplifier includes a 31-band equalizer, adjustable crossovers, time alignment, and multiple filter options to help create a customized listening experience.
