VENOM-12.D2

• Diameter: 12″ (30.5 cm)
• Basket: molded with ventilation holes.
• Voice coil: 3.0″ (76mm)
• Cone: unpressed cellulose.
• Lead wires: silver plated, flat.
• Voice coil: double, winding - round aluminum.
• Power: 1501 w / 3001 w
• Resistance: 2×2 Ohm
• Magnet weight: 219 Oz (6.2 kg)
• Sensitivity: 85.2 dB
• Total quality factor (Qts): 0.41
• Resonant frequency (Fo): 43Hz




  Diameter:	12" (30.5 cm)
  RMS/MAX Power:	1501 / 3001 W
  Frequency range:	30-400 Hz
  Sensitivity	8
  Resistance:	2x2 ohm
  Voice coil diameter:	3" (76 mm)
  Magnetic system weight	219 Oz (6.2 kg)
  Resonant Frequency (Fo):	43 Hz
  Mechanical quality factor (Qms):	2.28
  Electrical quality factor (Qes):	0.45
  Total quality factor (Qts):	0.41
  Equivalent volume (Vas):	12.83
  Movable system mass (Mms):	310 g
  Strength factor (BL):	24.38
  Coil resistance, Ohm (Re):	1.9 + 1.9
  Effective diffuser area (Sd):	729 cm2
  Suspension flexibility, mkm/H (Cms):	45.64
  Reference Efficiency (No):	0.188%
  Xmax:	40 mm
