Carsfy CLP3010 150W Fog Projector 3-Inch Bi-LED Solenoid Shutter Hi-Lo Beam H8 H11 Plug Play Die-Cast Housing Long Range Fog Carsfy India 2-Year Warranty
The Carsfy CLP3010 is a serious piece of engineering — 150W of bi-LED output through a 3-inch projector lens with a built-in electronic solenoid shutter that switches cleanly between low and high beam. It fits your existing fog lamp housing, connects to your factory H8/H11 wiring, and is sealed against rain, mud, and dust. At ₹19,490 with a 2-year warranty, it is Carsfy's most capable fog lamp — and it shows.
This blog covers every aspect of the CLP3010 — the technology behind the solenoid shutter, what 150W actually means in terms of road visibility, how a projector beam differs from a reflector fog lamp, installation process, car compatibility, and who should buy this over the alternatives. Read it fully before deciding.
What Makes the CLP3010 Different — The Technology Inside
Four Technologies Working Together
🔵
Bi-LED Light Source
Bi-LED means two separate LED arrays — one for low beam, one that adds to it for high beam. Both fire through the same 3-inch lens. Higher output, better thermal management, longer lifespan than single-LED designs.
🔩
Electronic Solenoid Shutter
A precision electromagnetic shutter positioned at the focal point of the projector lens. In low beam — shutter blocks upper beam to create a sharp cut-off. In high beam — solenoid pulls the shutter away, releasing the full unrestricted beam instantly.
🔍
Convex Glass Projector Lens
Precision-ground glass — not plastic — collects all LED light output and focuses it into a controlled, high-intensity beam. Glass maintains optical clarity over temperature cycles that plastic lenses degrade under.
🏗️
Die-Cast Thermal Shell
Thermal-conductive die-cast aluminium housing — dissipates heat from the 150W LED array efficiently. Heavier and more rigid than plastic housings — resists vibration, impact, and deformation on rough Indian roads.
⚡
Built-In Digital Driver
Internal smart circuitry monitors and regulates voltage — compensates for Indian vehicle voltage fluctuations (especially common in older cars). Eliminates flickering, power spikes, and premature LED failure.
🌊
Full Waterproof Sealing
Complete weather-proofing — seals against rain, road spray, mud, and dust. Rated for heavy monsoon driving conditions and off-road splashes. No lens condensation from temperature changes.
Low Beam & High Beam — How the Solenoid Shutter Works
The CLP3010's most important engineering detail is the internal electronic solenoid shutter — the mechanism that makes it a true bi-LED projector rather than a simple LED bulb replacement. Here's exactly how it works:
Solenoid Shutter Operation — Step by Step
💡
Both LED Arrays On
150W of bi-LED output active — all light collected by the projector bowl and directed toward the lens focal point
🔩
Shutter Position Controls Beam
Low beam: shutter blocks upper portion of light — creates sharp horizontal cut-off line. High beam: solenoid energises, shutter drops away — full unrestricted beam released
🔍
Lens Focuses & Projects
Convex glass lens collects and projects the shaped light as a precise, high-intensity beam — wide and road-hugging in low beam, long and penetrating in high beam
🔅
Low Beam Mode
Shutter Closed — Wide Road Coverage
Shutter blocks upper light — creates the sharp horizontal cut-off that defines a projector's signature look. Light spreads wide and flat across the road surface close to your car. Safe for oncoming traffic — no upper scatter, no blinding glare. Ideal for city driving, traffic, and fog conditions where close-range wide coverage matters more than distance.
Best for: City · Traffic · Fog · Rain
🔆
High Beam Mode
Shutter Open — Long Range Penetration
Solenoid energises instantly when you activate high beam — shutter retracts, releasing the full 150W output through the projector lens as a long, penetrating column of light. The precision convex glass focuses all 150W into a concentrated beam that throws far down the road ahead. On dark highways — NH-58, NH-44, rural state roads — high beam mode reveals hazards, animals, and road conditions hundreds of metres before your headlights do.
Best for: Highway · Rural roads · Dark stretches
⚡ Why Solenoid Shutter Beats Dual-Bulb Designs
Some cheaper bi-LED fog lights use two separate bulbs — one for low beam, one for high beam — switching between them electronically. The solenoid shutter design is superior: one optical system, one lens, one beam axis. The light path is identical for both beams — only the shutter position changes. This means no misalignment between lo and hi beam, no light loss from switching optics, and a dramatically sharper cut-off line than dual-bulb alternatives. The CLP3010's solenoid design is borrowed directly from premium OEM bi-xenon headlight projectors.
150W — What It Means on Indian Roads
Factory Fog vs CLP3010 — Real World Comparison
🕯️
Factory H11 Halogen Fog
55W halogen — approximately 700–1,000 lumens. Reflector housing scatters light in all directions including upward. Effective illumination range: 30–50 metres. In rain and fog: back-scatter reduces visibility further. The bulb that most Indian cars shipped with for 20 years.
⚡
Carsfy CLP3010 Bi-LED
150W bi-LED — multiple times the lumen output of factory halogen. Projector lens focuses all output in a controlled beam — no wasted upward scatter. Sharp cut-off prevents oncoming glare. Long-range high beam penetrates well beyond your headlights on dark roads. The difference is immediate and dramatic on first use.
🚗 What Changes After Installation — In Plain Terms
Your car's fog light slot goes from producing a dim, scattered glow that adds perhaps 10 metres of useful visibility, to projecting a focused, high-intensity beam that illuminates road surfaces, potholes, animals, and obstacles significantly further ahead. In monsoon rain — the projector's sharp cut-off means the beam stays on the road rather than back-scattering off rain droplets into your own eyes. On unlit state highways — the high beam mode gives you advance warning of hazards that factory lights would show you too late to respond. This is the practical impact of 150W through a 3-inch projector lens.
Why Projector Beats Reflector Every Time
The CLP3010 is a projector fog lamp — not a reflector. Here's why that distinction matters:
Standard Reflector Fog
Factory / Budget Reflectors
-
🔦Light scatters in all directions
-
⬆️Significant upward light — blinds oncoming
-
📉No true cut-off line
-
🌧️Back-scatter in rain reduces visibility
-
📏Limited distance coverage
-
💡Much output wasted
✦ CLP3010 Projector
Carsfy CLP3010 3" Bi-LED
-
🎯Light focused into controlled beam
-
✂️Sharp horizontal cut-off — no glare
-
✅Defined upper cut-off line
-
🌧️Projector optics reduce rain back-scatter
-
📏Long-range beam penetration
-
⚡All 150W used efficiently on road
Generic LED Bulb Swap
LED Bulb in Reflector Housing
-
💡More lumen but still reflector optics
-
⬆️Still scatters upward — glare issue
-
❌No cut-off — same scatter pattern
-
🌧️Rain scatter still problematic
-
📏Better than halogen but not focused
-
⚠️Housing limits optical performance
💡 The Cut-Off Line — Why It Matters
The CLP3010's sharp horizontal cut-off line is not just aesthetics — it's the feature that separates a safe lighting upgrade from an antisocial one. A proper projector cut-off means all the light goes onto your road surface. Oncoming drivers see no glare from your fog lights regardless of output wattage. You can run 150W confidently knowing you're not blinding other road users — the projector optics ensure every watt serves you, not them.
Installation — Simple 4-Step Process
Step-by-Step Installation Guide
1
Remove Existing Fog Lamp
From under the bumper or behind the wheel arch liner, locate and remove the screws or clips holding your factory fog lamp assembly. Disconnect the factory H8/H11 wiring connector from the back of the old fog lamp. The factory unit slides out cleanly — no cutting required on any standard Indian car.
2
Mount CLP3010 into Fog Lamp Slot
Insert the CLP3010 into the factory 3-inch round fog lamp opening using the included universal mounting clamp. Tighten the clamp to secure the projector body firmly. The die-cast housing is designed for the standard 3-inch round slot found in the majority of Indian cars — no fabrication or adapter required.
3
Connect H8/H11 Plug
Plug the CLP3010's H8/H11 play-coupler wire directly into your car's existing fog lamp connector — the same connector your factory fog lamp used. No relay, no LOC, no external wiring modification. The built-in digital driver handles voltage regulation and anti-flicker internally.
4
Align Beam and Test Both Modes
Turn on your fog lights to test low beam. Adjust the vertical angle of the projector using the mounting clamp so the cut-off line sits just below oncoming traffic eye level — approximately 1 metre high at 10 metres distance. Then activate high beam and confirm the solenoid shutter opens fully — you will see the beam extend significantly. Repeat both sides.
⏱️ Installation Time & Tools
Most cars: 20–30 minutes per side for an experienced installer. DIY first-timer: 45–60 minutes per side. All mounting hardware included in box. Tools needed: screwdriver or 8mm socket for bumper clips, small spanner for mounting clamp — both standard tools available in any toolkit. No special equipment required.
Frequently Asked Questions
Will the CLP3010 fit my car's fog lamp slot?
The CLP3010 is designed for standard 3-inch round fog lamp openings — the most common fog lamp slot size on Indian cars. It fits the vast majority of Indian passenger cars and SUVs including Maruti, Hyundai, Kia, Tata, Honda, Toyota, Mahindra, and Renault models. Confirm your fog lamp slot is a 3-inch round opening before ordering — if you're unsure, WhatsApp us at +91 97287 64403 with your car model and a photo of the fog lamp area and we'll confirm instantly.
How does the high beam switching work — do I need extra wiring?
No extra wiring needed. The CLP3010's solenoid shutter is controlled by your existing car wiring — when you activate your headlight high beam switch, the increased voltage signal that was always present in your fog lamp circuit triggers the solenoid to open. The built-in digital driver detects this and energises the solenoid shutter instantly. If your car's fog lights and high beam are on separate circuits, your installer can tap the high beam signal wire to trigger the solenoid — a simple wire connection that any electrician can do in minutes.
Is 150W safe for my car's electrical system?
Yes. The CLP3010's built-in digital driver regulates the actual current draw efficiently — the 150W figure is the optical equivalent output (effective LED system wattage), not the actual AC draw from your battery. Modern LED systems are far more efficient than halogen equivalents. The H8/H11 connector your car provides is rated well above the actual current draw of the CLP3010. No relay kit, fuse upgrade, or additional wiring is required.
Can I install the CLP3010 myself or do I need a professional?
Most mechanically confident car owners install the CLP3010 themselves — it's a plug-and-play system requiring no cutting, no splicing, and no special tools. The main steps are: remove factory fog lamp, mount CLP3010 in the same slot, plug in the H8/H11 connector, adjust beam angle. If you're comfortable changing a factory fog bulb, you can install this. For beam alignment accuracy and solenoid wiring (if needed), a local car electrician or accessories shop can complete installation in under an hour.
What does the 2-year warranty cover?
The 2-year Carsfy brand warranty covers manufacturing defects — LED array failure, solenoid shutter malfunction, driver circuit failure, and housing seal defects. Physical damage from accidents, incorrect installation, or voltage supply issues (using a faulty relay or incorrect wiring) are not covered. All purchases from Car Concepts Shop include the warranty card in the box. For warranty claims, contact us via WhatsApp at +91 97287 64403.
How does the CLP3010 compare to the Aozoom FLP2090 or GTR FL301M?
All three are 3-inch bi-LED projectors at premium price points — the choice depends on specific priorities. The CLP3010 (₹19,490) stands out with its 2-year warranty (longest in the segment) and 150W output. The Aozoom FLP2090 (₹17,149) is known for the distinctive Blue Quattro lens with white/yellow/dual switching. The GTR FL301M (₹8,699) is a laser projector at a lower price. The CLP3010 is for buyers who want maximum wattage and the longest warranty — Aozoom FLP2090 for tri-colour switching versatility — GTR FL301M for laser technology at accessible pricing.
Available Now — Same Day Dispatch
Carsfy CLP3010 — 150W Flagship Fog Projector
