Morel Kinetic KS124 12-Inch High-Performance Car Audio Subwoofer (350W RMS | 4-Ohm Single Voice Coil)

Product Overview

Unleash maximum deep-bass output, chest-thumping impact, and unyielding acoustic authority with the flagship Morel Kinetic KS124 12-inch component subwoofer. Engineered for enthusiasts who demand deep, room-shaking low frequencies, the KS124 delivers Morel’s signature musicality and clarity at an affordable price point.

Constructed with a 12-inch (305mm) high-rigidity composite cone, a high-capacity 2-inch voice coil, and an optimized magnet structure, the KS124 moves massive volumes of air with precise control and minimal distortion, making it the ultimate boot-mounted bass solution.

Key Features & Performance Highlights

• Maximum Air Displacement & Output: Large 12-inch (305mm) driver geometry generates deep, room-filling low-end bass extension down to ultra-low frequencies.

• 350W RMS / 700W Peak Power Handling: Built to handle continuous high-power signals for maximum sound pressure and bass impact.

• Heavy-Duty 2-Inch High-Temp Voice Coil: Ensures efficient heat dissipation and steady performance during high-volume playback.

• Rigid Treated Composite Cone & Surround: High-durability cone and surround material prevent physical distortion under extreme cone excursion.

• Universal 4-Ohm Impedance: Designed for easy pairing with a wide range of monoblock subwoofer power amplifiers.

Technical Specifications

• Brand & Series: Morel (Kinetic Series)

• Model: KS124

• Subwoofer Size: 12-Inch (305 mm)

• Nominal Impedance: 4 Ohms (Single Voice Coil)

• Power Handling (RMS): 350 Watts

• Peak Power Handling: 700 Watts

• Voice Coil Diameter: 2.0-Inch (50 mm)

• Cone Material: Treated Paper Composite

• Basket Type: Stamped Heavy-Duty Steel Frame

• Recommended Enclosure Type: Sealed or Slot-Ported Enclosures

Frequently Asked Questions (FAQs)

1. What type of bass performance can I expect from the Morel KS124?

The KS124 delivers deep, impactful, and smooth bass that easily fills the vehicle cabin. It excels across all genres of music, from hip-hop and EDM to rock and cinematic tracks.

2. What enclosure size is recommended for the 12-inch Morel KS124?

A sealed box of approximately 1.0 to 1.25 cu ft provides tight, accurate bass response. For maximum SPL and heavy sub-bass output, a custom slotted enclosure of 1.5 to 1.8 cu ft tuned between 32Hz and 35Hz is recommended.
