Pioneer TS-1601IN 2 Way Coaxial Speaker
Product Overview
Upgrade your car's audio system with the Pioneer TS-1601IN 2 Way Coaxial Speaker. With 320 watts of power, experience crystal-clear sound and immersive bass. The PIONEER technology ensures high-quality audio for an enhanced driving experience.
Product Features
- Type: Coaxial 2-WAY
- Sound pressure level: 88dB(±1.5dB)
- Frequency range: 30 Hz～35,000 Hz（－20ｄB）
- Maximum power: 320W
- Nominal power: 50W
- Cone size: 6-1/2' (φ160mm) Cone
- Impedance: 4 OHM
- Cone material: High rigid IMPP Cone
- Surround material: Light weight elastic polymer
TWEETER TYPE
Type: Dome
- Diaphragm material: Polyimide
- color: Black
INSTALLATION
- Weight: 0.64 kg
- Mounting depth: 53mm
- Cutout hole: 128mm
- Dimensions (Dia x Depth): Φ159 (mm) x 70.2 (mm)
Other features of TS-1601IN
Elastic polymer surround
Cone surround is made of elastic polymer for strong bass
Aluminum bobbin
High quality aluminium voice coil bobbin is used to safeguard from heat and prolong speaker life
Long Voice Coil
Enable large displacement. Helps in producing strong bass and High power handling.
High heat resistance
Made for Indian climatic conditions, especially extreme heat
Tweeter mounting option
Various mounting options are included in the package to install tweeter
Brand |
Pioneer |
|---|---|
|
Manufacturer |
Pioneer India Electronics Ltd, Tohoku pioneer vietnam co ltd, land plot G,Namura-haiphjong industrial Zone,An Hung Ward,An Duong Dist,Haiphong city, Vietnam |
|
Model |
TS-1601IN |
|
Model Name |
TS-1601IN |
|
Product Dimensions |
17.4 x 8.6 x 29.4 cm; 4.39 Kilograms |
|
Item model number |
TS-1601IN |
|
Mounting Hardware |
2 x Speakers, 2 x Speaker Wire, Warranty Card |
|
Speaker Connectivity |
Coaxial |
|
Wattage |
320.00 |
|
Batteries Included |
No |
|
Batteries Required |
Yes |
|
Manufacturer |
Pioneer India Electronics Pvt. Ltd. |
|
Imported By |
PIONEER India Electronics Pvt. Ltd. Unit No.3 10th Floor, Ambience Corporate Tower II,Plot No.3 Ambience Island, NH-8, Gurgaon - 122002, Haryana, India |
Frequently Asked Questions (FAQ)
Q: What does "Hi-Res Audio" mean for a car speaker?
A: Hi-Res Audio speakers are engineered to reproduce frequencies exceeding the standard CD limit (20 kHz), often extending up to 40 kHz or higher. This ultra-wide bandwidth preserves subtle atmospheric details, harmonics, and soundstage depth present in lossless audio formats (FLAC, ALAC, or high-bitrate streaming services).
Q: Will the Pioneer TS-160iIN fit in my car doors?
A: Yes, the TS-160iIN uses a standard 6.5-inch (165mm) frame size with a compact mounting depth, making it compatible with the standard speaker cutouts found in most hatchbacks, sedans, and SUVs.
Q: Do I need to play FLAC or Hi-Res files to enjoy these speakers?
A: No. While Hi-Res audio files yield the highest fidelity, the TS-160iIN's superior cone materials, low-distortion voice coils, and precision construction will make everyday Spotify, Apple Music, or FM radio sources sound significantly clearer and more dynamic than stock speakers.
Q: Can I run these speakers directly off my original car stereo?
A: Yes, these speakers feature high electrical sensitivity, allowing them to produce loud, detailed sound directly from a factory or aftermarket touchscreen head unit. However, adding an external 4-channel power amplifier will unlock deeper mid-bass extension and dynamic headroom.
