AES Turbo SV 3-Inch Laser-5 Square Bi-LED Headlight Projector Lens (65W Low / 100W High Beam | 6000K)

Next-Level Square Design & High-Power Laser Output: AES Turbo SV

Upgrade your front-end styling and highway visibility with the AES Turbo SV 3-Inch Square Bi-LED Projector. Featuring a distinctive modern square optical lens, double reflector design, and an integrated multi-laser diode module (65W Low Beam / 100W High Beam), this projector delivers an ultra-wide road spread with an extreme high-beam distance punch and razor-sharp cut-off line.

Key Features & Highlights

• Distinctive 3-Inch Square Lens Aesthetics: Futuristic square lens shape provides an aggressive, modern look that stands out inside custom headlight retrofits.

• Massive 100W High-Beam Laser Output: Dual reflectors paired with 6+2+3 LED chip architecture and laser assist project intense center illumination down long highways.

• Crisp 6000K Pure White Clarity: 6000K color temperature delivers excellent contrast, daylight-like illumination, and superior night road clarity.

• Sharp Cut-Off Line & Uniform Light Spread: Anti-glare low-beam pattern ensures maximum visibility without blinding oncoming traffic.

• Advanced Thermal Management: Engineered with heavy-duty aviation aluminum construction and an internal cooling system for stable long-term performance.

Technical Specifications

• Brand: AES

• Model: Turbo SV (Laser-5)

• Lens Shape / Size: Square 3.0 Inch

• Power Output: 65W Low Beam / 100W High Beam

• Color Temperature: 6000K (Pure Cool White)

• Operating Voltage: 9V – 16V DC

• Light Source: Dual Reflectors + 6+2+3 LED Chips + Laser Module

• Operating Temperature: -40°C to +105°C

• Lifespan: 30,000+ Hours

• Fitment Type: Universal 3.0" Square Headlight Retrofit

Frequently Asked Questions

What is the advantage of the square lens design on the AES Turbo SV?

The square optical lens offers a modern, aggressive appearance for custom retrofits while maintaining precise light distribution, wide coverage, and a sharp cut-off line equivalent to traditional round lenses.
